Sale!

HDPE-CD 110 mm OD, With 5 Sub-ducts, 33 mm OD

ر.س16.50 ر.س15.00

Availability: 25000 in stock

Add to Wishlist
Add to Wishlist
Category:

HDPE CD 5X33 MM
* HDPE-CD, Main Duct
Material-HDPE,PE100
Nominal Outside Diameter-110 ± 2 mm
Nominal Inner Diameter-90 ± 2 mm
Wall Thickness-2.5 ± 0.5 mm
Color-Bright Orange
Pipe Stiffness @ 5% Deflection-15 kgf/cm²
Compressive Strength @5% Deflection-660 kgf/m

**HDPE , 5 Sub-Duct
Material-HDPE,PE100
Nominal Outside Diameter-33 ± 1 mm
Nominal Inner Diameter-28 ± 1 mm
Wall Thickness-2.5 ± 0.5 mm
Color-Green, Blue, Orange, Black & White/Custom
Nominal Pressure (Sub-duct)-16 Bar

***HDPE-CD ( with 5-33 mm OD sub-ducts )
Pipe Stiffness @ 5% Deflection-27 kgf/cm²
Compressive Strength @5% Deflection-1,200 kgf/m
Compound Density @ 25°C-0.95 g/cm3, min
Tensile Strength @ Yield (film properties)-30 MPa
Elongation @ Break (film properties)-400%.
Carbon Black Content-2%
Water Absorption-0.03%, maximum
Voltage Resistance-2,000 Vac, (> 15 min.)
Insulation Resistance-> 200 Mohm
